Neumann TLM 170 R kondenzatorski mikrofon

2700

Besplatna dostava
Besplatna dostava je za sve artikle koji su plaćeni preko 15.000 dinara. Svaka pošiljka može biti osigurana dodatno/pošiljke do 70 000 dinara su osigurane.

Cenovnik dostave
Klikom na link posetićete stranicu sa ažuriranim cenovnikom kuriskih službi.

Načini plaćanja
Naručivanje preko našeg sajta u proseku traje manje od jednog minuta i odvija se kroz nekoliko jednostavnih koraka.

Opis proizvoda

The TLM 170 R* was the first microphone to use the successful fet 100 technology. Along with a balanced, transformerless output stage it features extremely low self-noise and an impressive dynamic range. Five directional characteristics are selectable by means of a rotary switch. In the sixth position, marked

Tehničke specifikacije proizvoda

  • Acoustical operating principle Pressure gradient transducer
  • Directional pattern Omnidirectional, wide angle cardioid, cardioid, hypercardioid, figure-8
  • Frequency range 20 Hz ... 20 kHz
  • Sensitivity at 1 kHz into 1 kohm 8 mV/Pa
  • Rated impedance 50 ohms
  • Rated load impedance 1 kohms
  • Equivalent noise level, CCIR1) 26 dB
  • Equivalent noise level, A-weighted1) 14 dB-A
  • Signal-to-noise ratio, CCIR1) (rel. 94 dB SPL) 68 dB
  • Signal-to-noise ratio, A-weighted1) (rel. 94 dB SPL) 80 dB
  • Maximum SPL for THD 0.5%2) 144 dB
  • Maximum SPL for THD 0.5% with preattenuation2) 154 dB
  • Maximum output voltage 10 dBu
  • Dynamic range of the microphone amplifier (A-weighted) 130 dB
  • Supply voltage (P48, IEC 61938) 48 V ± 4 V
  • Current consumption (P48, IEC 61938) 3 mA
  • Matching connector XLR3F
  • Weight 625 g
  • Diameter 60 mm
  • Length 152 mm
