LD Systems DSP 45 K pojačalo

RSD275.760,00
(cena je sa uračunatim PDVom)
Vreme isporuke: 7 do 10 dana

Besplatna dostava
Besplatna dostava je za sve artikle koji su plaćeni preko 15.000 dinara. Svaka pošiljka može biti osigurana dodatno/pošiljke do 70 000 dinara su osigurane.

Cenovnik dostave
Klikom na link posetićete stranicu sa ažuriranim cenovnikom kuriskih službi.

Načini plaćanja
Naručivanje preko našeg sajta u proseku traje manje od jednog minuta i odvija se kroz nekoliko jednostavnih koraka.

Opis proizvoda

The LD Systems® DSP 45 K is a professional 4-channel power amplifier with extensive DSP control. Designed for demanding large-scale sound reinforcement and concert-quality performance, it delivers a massive 1,200 watts per channel and 2 x 2,400 watts bridged. The high-efficiency Class H topology and switch mode power supply with power factor correction (PFC) provide a wide dynamic range and excellent transient response. The DSP 45 K features comprehensive protection circuitry including power-up, DC, overcurrent, thermal and short circuit protection plus current and clip limiters to prevent SMPS overload and loudspeaker damage. Together with a pair of temperature controlled fans, they ensure exceptional reliability in the most demanding applications. The 24-bit DSP allows precise control with FIR and IIR filters, parametric EQ, crossover, delay, RMS and peak limiter functions. User configurable loudspeaker presets with password protection enable fast setup. The DSP 45 K is housed in a dual rack space all-steel chassis and weighs just 7 kg. It provides balanced Neutrik® XLR inputs, speakON® output connectors plus USB and Ethernet ports. The front panel sports a menu driven 4-line display and rotary encoder with push button switch for easy configuration. For optimal speaker performance and safe operation the DSP 45 K comes with an LD Systems® loudspeaker preset library, and the included software enables computer control and monitoring.



Tehničke specifikacije proizvoda

  • Product number: LDDSP45K
  • Product type: Power Amplifiers
  • Type: 4-channel
  • Rated ouput power (1kHz @ 2 Ohms): 4 x 1200W
  • Rated ouput power (1kHz @ 4 Ohms): 4 x 1200W
  • Rated ouput power (1kHz @ 8 Ohms): 4 x 675W
  • Rated ouput power (1kHz @ 4 Ohms, bridged): 2 x 2400W
  • High Z 70Vrms / 100Vpeak: 4 x 1200W
  • High Z 100Vrms / 140Vpeak: 2 x 2400W
  • Output circuitry: Class H
  • Frequency response: 10 - 22000Hz
  • THD: < 0.05 % @ 1 kHz
  • Signal-to-noise ratio: 104dB
  • Protection circuits: over-current, RMS speaker limiter, short circuit, DC protection, Multiband limiter, clip limiter, soft start, thermal protection
  • Controls: Direct access buttons, On / off switch, knob, Exit / lock button
  • Indicators: LC display
  • Line inputs: 4
  • Line input connectors: Neutrik XLR
  • Line outputs: 4
  • Line output connectors: Neutrik XLR
  • Loudspeaker outputs: 4
  • Speaker output connections: Speakon
  • Cooling: 2 fans, temperature controlled
  • Maximum Ambient Temperature: 0 - 40°C
  • Operating voltage: 220 V AC - 240 V AC, 50-60 Hz, Switching power supply
  • Relative Humidity:: < 80% (non-condensing)
  • Power consumption @ full load: 1900 W
  • Width: 482mm
  • Height: 89mm
  • Depth: 320mm
  • Weight: 7,9kg
  • Features: 19" / 2 U, DSP controlled, Active Power Factor Correction
